I. Core Pain Points in High-Concentration Sludge Conveying: Why Do Feed Pumps Frequently Fail?

To solve the conveying challenges, it is first necessary to clarify the fundamental differences between high-concentration sludge and ordinary sewage, as well as the specific impacts of these differences on feed pumps:

High Viscosity Causes "Sharp Increase in Conveying Resistance"

The viscosity of high-concentration sludge (such as excess activated sludge and digested sludge) can reach several hundred to several thousand cP (ordinary water is only 1 cP). During flow, it needs to overcome greater pipeline friction and internal resistance in the pump cavity. If the "flow capacity" of the feed pump is insufficient, problems such as flow attenuation, insufficient head, and even "sludge retention and caking" inside the pump cavity are likely to occur. This leads to unstable feeding pressure of the filter press and an increase in the moisture content of the filter cake.

High Impurity Content Triggers "Wear of Flow-Passing Components"

Sludge in sewage treatment plants often contains hard impurities such as sand particles, fibers, hair, and gravel (especially in municipal sewage and industrial wastewater treatment scenarios). When these impurities flow through the flow-passing components of the pump (such as the impeller, pump casing, and mechanical seal) at high speed along with the sludge, they cause "erosive wear". This results in increased impeller clearance, thinning of the pump casing, and leakage of the mechanical seal—not only reducing the pump’s conveying efficiency but also causing failures such as liquid leakage and increased noise, thereby shortening the equipment’s service life.

Easy Sedimentation Leads to "Blockage of Pipelines and Pump Cavity"

High-concentration sludge has "poor suspension stability"; when it is stationary or the flow rate is too low, solid particles tend to settle. If the inlet pipeline of the feed pump is unreasonably designed (e.g., excessively small diameter, too many elbows) or the pump is not fully "pre-stirred" before startup, the settled sludge will block the pump’s inlet pipeline or impeller channels. This causes the "pump to run idly" (no material conveyed) and may even burn out the motor.

Flow Fluctuation Affects "Stable Operation of the Filter Press"

Filter presses have high requirements for the stability of feed flow and pressure: in the initial stage, low pressure and large flow are needed to quickly fill the filter cavity; in the middle stage, the pressure needs to be gradually increased to compact the sludge; in the later stage, pressure maintenance is required for filtration. If the feed pump has poor flow and pressure regulation capabilities (e.g., using a fixed-speed pump), problems such as slow initial filling, sudden pressure rise in the middle stage (causing filter cloth damage), and insufficient pressure maintenance in the later stage are likely to occur—seriously affecting the filter press cycle and filter cake output.

II. Targeted Solutions: Building an Efficient Conveying System from "Pump Type Selection" to "Material Matching"

To address the challenges of high-concentration sludge conveying, it is necessary to start with "source optimization"—that is, selecting a suitable feed pump based on sludge characteristics, and matching it with appropriate flow-passing materials, pipeline design, and control methods. Specifically, this can be divided into the following 4 core links:

Pump Type Selection: Prioritize pumps with "high flow capacity and anti-clogging performance"
Flow-Passing Material Selection: Make "proper matching" according to the corrosiveness of sludge and the hardness of impurities
Pipeline and Installation Design: Avoid "sedimentation and blockage" and reduce conveying resistance
Control Method: Variable-frequency speed regulation + pressure feedback to adapt to the "variable working condition" requirements of the filter press

III. Practical Optimization: Daily Maintenance and Operation Tips to Extend Pump Life and Improve Efficiency

Even if the correct pump type and material are selected, malfunctions may still occur if daily operation and maintenance are improper. The following 5 practical tips can effectively reduce the incidence of malfunctions and extend the service life of the feed pump.

For Feed Pumps of Filter Presses in Sewage Treatment Plants: Addressing High-Concentration Sludge Conveying Challenges

The core to tackling high-concentration sludge conveying challenges lies in "appropriate pump selection, proper material matching, rational design, and thorough maintenance":

Pump Selection: Based on sludge viscosity, impurity content, and flow requirements, prioritize anti-clogging pump types such as screw pumps and diaphragm pumps.
Flow-Passing Material Selection: Combine sludge corrosiveness and impurity hardness to choose wear-resistant/corrosion-resistant materials like high-chromium cast iron, stainless steel, and ceramics.
Pipeline Design: Follow the principle of "large pipe diameter and fewer elbows", control flow velocity, and prevent sedimentation.
Control System: Adopt variable-frequency speed regulation + pressure feedback control to adapt to the variable working condition requirements of the filter press.
Daily Operation: Emphasize sludge agitation before startup, real-time monitoring during operation, and cleaning after shutdown; replace vulnerable parts regularly.

Through the above strategies, problems such as blockage, wear, and low efficiency in high-concentration sludge conveying can be effectively solved. This enables the coordinated and efficient operation of filter presses and feed pumps, reducing the operation and maintenance costs of sewage treatment plants as well as the energy consumption of sludge treatment.
